TiO₂ Nanoparticles for Solar Cell
As the world pivots toward clean energy, solar power stands at the forefront. But to improve the efficiency, durability, and cost-effectiveness of solar cells, advanced nanomaterials are critical.
Titanium Dioxide (TiO₂) nanoparticles have emerged as one of the most reliable and versatile materials for photovoltaic applications. Their exceptional electronic properties, wide bandgap, and high chemical stability make them ideal for use in dye-sensitized solar cells (DSSCs), perovskite solar cells, and photocatalytic devices.
At Schnaiffer, we synthesize high-purity TiO₂ nanoparticles optimized for solar cell fabrication, R&D, and prototyping across academic and industrial labs.
Why TiO₂ Nanoparticles for Solar Cells ?
- Efficient Electron Transport: Facilitates charge separation and mobility
- Scattering Layer Role: Enhances light absorption in multi-layer devices
- Photostability: Supports long-term device durability
- Low-Cost and Abundant: Ideal for scaling up production
- Eco-Friendly: Non-toxic and environmentally safe material
Applications
- Dye-Sensitized Solar Cells (DSSCs)
- Perovskite Solar Cells (as electron transport layer)
- Quantum Dot Solar Cells
- Photocatalytic Hydrogen Production Panels
- Transparent Solar Panels (TiO₂ in mesoporous layer)
Our Fabrication Process
At Schnaiffer, we produce TiO₂ nanoparticles using a sol-gel synthesis route, followed by thermal treatment for phase control and particle size tuning.
- Particle Sizes Available: 10 nm – 100 nm
- Crystalline Forms: Anatase, Rutile
- Purity: >99.5%
- Dispersibility: Aqueous and organic solvent compatible
- Surface Area: 50–200 m²/g (BET-tested)
- Optional Treatments: Surface functionalization for dye or perovskite anchoring
Typical Challenges Solved
Low dye-loading in DSSCs
High surface area anatase particles enable better dye adsorption
Instability under UV
UV-resistant rutile blends available
Electron recombination
Controlled pore structure for directional
electron transport
Low light capture
Scattering-grade TiO₂ available for rear reflective layers
Compatibility and Integration
Our nanoparticles are compatible with:
- Standard DSSC dyes (e.g., N719, Z907)
- Perovskite materials (e.g., MAPbI₃, FAPbI₃)
- Transparent conductive oxides (ITO/FTO)
- Roll-to-roll printing and screen printing
- Layer-by-layer film deposition techniques
Research Validation & Performance Data
TiO₂ nanoparticles from Schnaiffer have enabled:
- DSSC efficiencies up to 11.2% in lab conditions
- Over 1000 hours of stable performance in UV exposure tests
- Enhanced power output in bilayer perovskite cells
- Light harvesting across 300–700 nm with tuned particle morphologies
We provide test samples with full characterization data and application notes for multiple cell architectures.
Partner with us
Why Choose Schnaiffer?
Why Choose Schnaiffer?
Why Choose Schnaiffer?
- Scientific Rigor: Born out of nanotechnology research at BITS Pilani
- Custom-Built: We tailor particles to your cell desig
- Affordable: Low MOQ for research labs
- Eco-Conscious Manufacturing: Solvent recovery and waste-neutralization system
Technical Support
Why Choose Schnaiffer?
Why Choose Schnaiffer?
With each order, we provide:
- XRD for phase identification
- SEM/TEM images for morphology analysis
- BET surface area report
- Zeta potential and dispersion profile
- User guide for DSSC/perovskite layer formation
- Device prototyping support
How to Order
Why Choose Schnaiffer?
How to Order
Email us:
- Desired particle size and phase
- Application (DSSC, Perovskite)
- Quantity needed
